Clements Hiflo2 High Suction Pump

Description

Clements Hiflo2 High Suction Pump

Clements HiVac and HiFlo suction pumps feature advanced oil-less twin piston pump technology and have been designed for all high suction, high flow applications. Virtually maintenance-free, these units represent the ultimate in affordable and reliable mobile suction.

• Vacuum range up to -90kPa (-675 mmHg)
• Flow rate up to 90 litre/minute
• Quiet continuous operation (46.4 dBA)
• 3-stage overflow protection
• Dual scale gauge in kPa and mmHg
• Stable mobility, 4 x dual-track castors, 2 with brakes
• Minimal maintenance and easy-to-clean
• Shatter-resistant polycarbonate collection canisters
• Adaptable for use with disposable liner canisters
• Service kits and spare parts are available

Clements Hiflo2 High Suction Pump – Specifications

Code: HiFlo2 SUC84602

• Power Rating: 220 – 240 V 50/60 Hz 380W
• Maximum Vacuum: -90 kPa [-675 mm Hg]
• Maximum Flow Rate (free air): 90 litre/min
• Maximum Flow Rate (through jar): 80 litre/min
• Noise Level: 46.4 dBA
• Operation Mode: Continuous operation
• Gauge: 63 mm diameter, Bourdon tube type, dual scale, graduated in kPa and mmHg
• Gauge Range: 0 to -100 kPa graduated at 5 kPa, 0 to -760 mmHg graduated at 20 mmHg
• Vacuum Regulator: Needle valve type
• Pump Type: Twin-piston, oil-free
• Motor: Permanent split capacitor
• Housing: Smooth Clean ABS
• Filter: Disposable Hydrophic and Antibacterial, 0.3 micron
• Collection Canister Reusable (standard): 2 x 2 litre autoclavable, shatterproof polycarbonate jar, screw lid with integrated handle
• Overflow Protection: Positive Shut-off Float Valve in External Trap Jar
• Collection Canister Disposable Liner (Option): 2 x 3-litre disposable liner system (Requires optional matching support jar and ring bracket)
• Overflow Protection in Disposable Liner Canister: Inbuilt hydrophobic and antibacterial filter
• Dimensions Unit: 850 H x 460 W x 420 D mm   Packed: 910 H x 500 W x 500 D mm
• Weight: 16.5 kg
• Unit Weight: Packed Weight: 22kg
• GMDN  63642
• Device Class: IIa
