Advanced Instruments PM2000XL-Plus Patient Monitor with EtCo2

Description

Advanced Instruments PM2000XL-Plus Patient Monitor with EtCo2

You may be right in recognising this model, its a rebadged EDAN iM70.

Now we can offer this at a realistic and fair price to the market – no ripoff merchants here!

The Advanced PM-2000XL-Plus is a versatile, multi-functional patient monitor designed for use in various medical settings, including ambulatory, emergency care, intermediate care, and rehabilitation
It features a high-resolution colour TFT LCD display and full touch-screen operation, allowing intuitive control by clicking parameters or waveforms

The monitor includes comprehensive functionalities such as pacemaker detection, nurse call function, defibrillation protection, and synchronisation Additionally, it offers extended full-disclosure trend information, arrhythmia analysis, ST-segment analysis, and multiple optional parameters like IBP, cardiac output and anaesthesia gas monitoring.

Its compact design ensures portability and ease of use, making it suitable for both bedside and central monitoring

Offered config:

• PM-2000XL Main Unit
• Printer
• G2 EtCo2 Module
• 3/5 Lead ECG (3-Lead cable)
• Skin Temp with probe
• Adult Sp02 Accessories
• Child/Adult/L-Adult NIBP Cuffs
• 25 Pce O2/Co2 Cannula
• Advanced Instruments PM2000XL Patient Monitor with EtCo2 – Specifications

Safety Standards Safety Standards: IEC 60601-1+A1+A2; IEC 60601-2+A1; IEC 60601-1-8 (Alarm)

Advanced Instruments PM2000XL-Plus Patient Monitor with EtCo2 – Specifications

Physical Specifications:
Dimensions: 328mm (L) x 158mm (W) x 285mm (H)
Weight Standard configuration: 5.5kg

Display
Display: 12.1” Color TFT LCD Touch-screen
Resolution: 800 X 600 dpi
Traces Displayed: Up to 8
Waveforms Displayed Up to 11
Various Workings: Standard Monitoring Display
Selectable Interface: Large Font Intensive Care Display / Trend Graph/Monitoring Co-Display / Bed to Bed view
display (Optional) / OxyCRG Dynamic View display / Drug Dose Calculation Interface.
Sweep Speed: 6.25mm/s, 12.5mm/s, 25mm/s, 50mm/s

Environment Requirement:
Ambient Temperature
-20ºC – 55ºC (-4 – 131ºF)
Humidity: 15%-95% non-condensing

Power Supply
AC Power Supply: 100-240V AC, 50/60HZ
Internal Battery: 14.8 Rechargeable Li-ion Battery / 4200 mAh 14.8 V DC
Battery Working Period: Up to 6hours
Recharging Time:: <150minutes (2100 mAh) / <360minutes (4200 mAh)

Resp
Method: Trans-thoracic impedance
Operation Mode: Auto/Manual
Rr Measurement Range Adult: 0-120bpm / Neonate/Pediatric: 0-150Bpm
Resolution: 1 bpm
Apnea Alarm: Threshold 10s, 15s, 20s (default), 25s, 30s, 35s, 40s
Alarm: 3 levels of audible and visual alarm, Alarms events recallable
Band Width: 0.2-2.5Hz (-3dB)
Sweep Speed: 6.25mm/s, 12.5mm/s, 25mm/s, 50mm/s

ECG
Lead Type: 5-lead and 3-lead selectable
3 Leadwire Cable: RA; LA; LL or R; L; F
5 Leadwire Cable: RA; LA; RL; LL; V or R; L; N; F; C
Lead Selection: 3-lead: I; II; III / 5-lead: I; II; III; aVR; aVL; aVF; V
Gain Selection: x0.125: x0.25: x0.5; x1; x2; auto
Sweep Speed: 6.25mm/s, 12.5mm/s, 25mm/s, 50mm/s
Ecg Hr Range Resolution & Accuracy Filter: Adult/ Pediatric: 15-300bpm / Neonate: 15-350bpm
Resolution & Accuracy:±1bpm or ±1%, whichever is greater
Filter:Diagnosis mode: 0.05-150Hz / Monitoring mode: 0.5-40Hz / Surgical mode: 1-20Hz
Protection: Withstand 5000VAC/50Hz voltage in isolation against defibrillation, electrosurgical interference
St-Segment Detection: Measurement range: -2.0mV ~ 2.0mV / Alarm range: -2.0mV ~ 2.0mV
Comes With St-segment Arrhythmia Analysis And Categorization
Alarm: 3 levels of audible and visual alarm, alarm events recallable
Pace Maker Detection: Yes, and 5 types abnormal status detectable / IEC 60601-2-25; AAMI EC 11 / EC 13 IEC 60601-2-27

NIBP
Method: Automatic Oscillometric
Operations Modes: Manual / Automatic/ Continuous
Auto Measurement Time Interval: Adjustable 1, 2, 3, 4, 5, 10, 15, 30, 60, 90, 120, 240, 480 minutes.
Measurement Unit Mmhg/kpa Selectable
Measurement Types Systolic, Diastolic, Mean
Pressure Range Adults Systolic: 40 – 270 mmHg / Diastolic: 10 – 215 mmHg / Mean: 20 – 235 mmHg
Pressure Range Pediatrics: Systolic: 40 – 200 mmHg / Diastolic: 10 – 150 mmHg / Mean: 20 – 165 mmHg
Pressure Range Neonates: Systolic: 40 – 135 mmHg / Diastolic: 10 – 100 mmHg / Mean: 20 – 110 mmHg
Resolution: 1mmHg:
Accuracy: Max mean error ±5mmHg / Max standard deviation ±8mmHg
Alarm: Systolic, Diastolic, Mean
PR From NIPB Measurement: 40-240 bpm
Resolution 1 bpm
Accuracy ±3bpm or 3% whichever is greater. Comes with leak test and pressure auto calibration / IEC 60601-2-30 / SP10: 2002

SPO2

Measurement/Alarm Range: 0 – 100% (SpO2)
Resolution: 1%
Accuracy” ±2% (70-100% Adult/Pediatric); / ±3% (70-100% Neonate)
PR Measurement: 25 – 300 bpm
Resolution: 1bpm
Accuracy: 3bpm
Refresh 1s ISO 9919

Recorder:
Print Speed: 25mm/s, 50mm/s
Paper Width: 50mm /
Record width: 48mm
Built-in direct thermal pixel array recorder
Up to 3 channels printing and 1,2,3 channels selectable
