EnMind EN-V7 Touch Screen SMART Infusion Pump

$1,250 + GST

EnMind V7 Touch Screen Smart Infusion Pump. Very simplistic operation.
Long battery Life, Compact design, Top-end features
EN-D7 Docking station compatable – join the party with other V7 or S7 Syringe drivers – no tangles with multiple power cables.
Please allow 4 – 5 weeks for delivery.


SKU EMNI-ENS7 Category


Share
Description

EnMind EN-V7 Touch Screen SMART Infusion Pump

Product features:

  • Workstation docking station compatable – quick release system to docks, 2, 4, 6, 8 bay systems available.
  • Uses any standard IV sets and stores up to 20 editable brands 4.3 inch color touch screen, parameter setting and editing directly.
  • Multi-function operation with 3 modes: ml/h (time.rate mode); Body-weight mode and Micro-mode
  • Electric door and anti-free flow clip patented design
  • Flow rates range from 0.01 ml/h to 2,000ml/h with increment of 0.01 ml/h
  • Double CPU for increased safety,Ultrasonic air-in-line detector
  • Optional wireless connection to the C7 Central Station
  • Historic record more than 5000 logs
  • 9 hours battery back-up time

Basic parameters :

Screen: 4.3 inch LCD color Touch Screen
Infusion mode: ml/h (include rate mode, time mode), Body weight, Drip, loading-dose, ramp up/down, sequence, drug library mode
Accuracy: ±5%
Flow rate range: 0.01-1200 ml/h (min. increment 0.01ml/h)
VTBI: 0-9999ml
KVO: 0.01-5ml/h adjustable
Bolus rate: 0.1-1200ml/h (automatic and manual bolus available)
Occlusion level: 12 levels selectable

Interface: MINI USB
Wireless: Wifi (optional)

Alarm type:
VTBI infused, pressure high, Check upstream, battery empty, KVO finished, Door open, bubble, VTBI near end, battery  near empty, reminder alarm, no power supply, Drop sensor connection, System error, etc.

Special features :

Titration: Change flow rate without stopping infusion
Last therapy: Last therapies can be stored and used for rapid infusion
Drug library: No less than 2000 drugs
Anti-bolus: Automatic drop line pressure to reduce bolus impact after occlusion
Purge: Remove the air bubble
Screen lock: Avoid misoperation
Standby mode: Standby time 00-99h59m adjustable
Relay mode: Different pumps work in sequence on infusion workstation (optional)
Micro mode: Limit the max  infusion rate to double ensure patient safety

DPS: Real-time pressure display in graphically  and numerically
Brightness: Adjustable
Alarm volume: Adjustable
History record: More than 5000 entries

Power source :

AC Power: 110V-240V, 50/60Hz
External DC Power: 12V

Battery:
Lithium polymer battery 11.1V 2600mAh
More than 9 hours operating time @ 5ml/h
Less than 5 hours for fully charged

Others :

Classification: Class I, CF
Waterproof: IP24

Additional information
Weight5 kg
